Mug rack from boat-dock cleats
If you've ever pulled a rotten dock and saved the cleats, this is the project for them. Cast aluminum boat cleats, screwed to a piece of cedar, mounted on the wall under the coffee station. Mugs hang from the horns. The rack looks like it was always there. If you don't have salvaged cleats, the marine-supply store sells them for ten dollars apiece - they're worth it.
Materials
- Four cast-aluminum boat cleats, four to six inch
- Cedar 1x6, 24 inches long
- Eight stainless #10 wood screws, 1.25 inch
- Two keyhole picture-frame hangers
- Sandpaper
- Spar varnish or tung oil
Tools
- Drill with countersink bit
- Mitersaw or handsaw
- Speed square
- Pencil
- Tape measure
- Random-orbit sander
Build it
Cut and sand the backboard
Cut the cedar to 24 inches. Sand to 180. Round all four corners by hand with the sander - cedar that has been outdoors for a few seasons will already have rounded corners, so match the look you want.
Lay out the cleat positions
Mark four cleat centers on the cedar, evenly spaced, about five inches apart, centered top to bottom. The cleats need enough room between them that a coffee mug hung from one cleat doesn't bump the next. Five inches is the minimum for standard mugs - measure your favorite one and add an inch.
Drill mounting holes through the cleats
Most cast cleats have two through-holes already cast into the base. Use them as templates - clamp the cleat to the cedar at its mark and drill pilot holes through the cleat into the wood. If your cleats don't have through-holes, drill new ones through the cleat with a metal bit before mounting.
Mount the cleats
Drive a stainless screw through each cleat hole into the cedar. Snug them down - cast aluminum cracks if you over-torque, so stop the moment the cleat sits flat against the wood.
Add keyhole hangers and finish
Screw two keyhole hangers to the back of the cedar, four inches in from each end. Apply two coats of spar varnish for a damp cabin or one coat of tung oil for a dry one. Mount the rack with two pan-head screws into wall studs. Hang mugs.
Tested on my own porch.
